 단상 유동 전동기 (표준형)
SINGLE PHASE INDUCTION MOTORS STANDARD TYPE |
FRAME
NO |
OUT PUT |
DIMENSION(mm) |
KEY SIZE |
BEARING |
NET
WEIGHT
(kg) |
| KW |
FIG |
L
|
S
|
Q
|
A
|
B
|
C
|
D
|
E
|
H
|
I
|
K
|
M
|
N
|
O
|
U
|
T
|
F
|
G
|
V
|
LOAD |
UN-LOAD |
|
*71
|
0.2
|
|
230
|
200
|
138
|
112
|
90
|
45
|
14h6
|
30
|
71
|
150
|
7
|
118
|
134
|
67
|
110
|
13
|
-
|
-
|
25
|
6202zz
|
6202zz
|
7
|
|
71
|
0.25
|
|
240
|
210
|
138
|
112
|
90
|
45
|
14h6
|
30
|
71
|
150
|
7
|
118
|
134
|
85
|
110
|
13
|
-
|
-
|
25
|
6202zz
|
6202zz
|
8
|
|
*80
|
0.4
|
Ⅱ
|
287
|
247
|
153
|
125
|
100
|
50
|
16j6
|
40
|
80
|
165
|
10
|
126
|
145
|
88
|
130
|
13
|
5
|
5
|
30
|
6203zz
|
6202zz
|
10
|
|
90
|
0.4
|
Ⅱ
|
261
|
221
|
173
|
140
|
100
|
56
|
19j6
|
40
|
90
|
19
|
10
|
139
|
165
|
92
|
130
|
15.5
|
6
|
6
|
30
|
6204zz
|
6203zz
|
11
|
|
90
|
0.55
|
Ⅱ
|
276
|
236
|
173
|
140
|
125
|
56
|
19j6
|
40
|
90
|
190
|
10
|
139
|
165
|
97
|
155
|
15.5
|
6
|
6
|
30
|
6204zz
|
6203zz
|
13
|
|
*90L
|
0.75
|
Ⅱ
|
291
|
251
|
173
|
140
|
125
|
56
|
19j6
|
40
|
90
|
190
|
10
|
139
|
165
|
97
|
155
|
15.5
|
6
|
6
|
30
|
6204zz
|
6203zz
|
16
|
|
90
|
1.1
|
Ⅱ
|
311
|
271
|
173
|
140
|
125
|
56
|
19j6
|
40
|
90
|
190
|
10
|
139
|
165
|
101
|
155
|
15.5
|
6
|
6
|
30
|
6204zz
|
6203zz
|
28
|
|
114
|
1.1
|
Ⅱ
|
314
|
264
|
223
|
190
|
114
|
70
|
22h6
|
50
|
114.3
|
224
|
12
|
173
|
217
|
122
|
165
|
18
|
7
|
7
|
40
|
6206zz
|
6204zz
|
21
|
|
114S
|
1.5
|
Ⅱ
|
329
|
279
|
223
|
190
|
114
|
70
|
22h6
|
50
|
114.3
|
224
|
12
|
173
|
217
|
129
|
165
|
18
|
7
|
7
|
40
|
6206zz
|
6204zz
|
32
|
|
114M
#184T
|
2.2
|
|
349
359
|
289
289
|
223
272
|
190
190
|
140
140
|
70
70
|
28h6
28.5h6
|
60
70
|
114.3
114.3
|
224
224
|
12
12
|
173
199
|
217
217
|
150
109
|
165
165
|
24
25
|
7
6.35
|
7
6.35
|
50
45.2
|
6206zz
6206zz
|
6204zz
6204zz
|
35
36
|
|
114L
#184T
|
3.7
|
|
359
394
|
299
324
|
272
272
|
190
190
|
140
140
|
70
90
|
28h6
28.5h6
|
60
70
|
114.3
114.3
|
224
224
|
12
12
|
173
199
|
217
217
|
133
109
|
165
165
|
24
25
|
7
6.35
|
7
6.35
|
50
45.2
|
6206zz
6206zz
|
6204zz
6204zz
|
38
40
|
|
#215T
|
5.5
|
|
448
|
362
|
305
|
216
|
178
|
90
|
34.9h6
|
86
|
133.3
|
255
|
11
|
257
|
243
|
122
|
215
|
30.5
|
7.92
|
7.92
|
62
|
6307zz
|
6305zz
|
61
|
|
#215T
|
7.5
|
|
488
|
402
|
305
|
216
|
178
|
90
|
34.9h6
|
86
|
133.3
|
255
|
11
|
257
|
243
|
122
|
215
|
30.5
|
7.92
|
7.92
|
62
|
6307zz
|
6305zz
|
70
|
 |
단상 유동 전동기 (진상형)
SINGLE PHASE INDUCTION MOTORS CAPACITOR RUN TYPE |
| :: 단상 유도전동기(진상형) 4극(POLES) :: |
|
FRAME
NO
|
OUT PUT
|
DIMENSION(mm)
|
KEY SIZE
|
BEARING
|
NET
WEIGHT
(kg)
|
|
KW
|
FIG
|
L
|
S
|
Q
|
A
|
B
|
C
|
D
|
E
|
H
|
I
|
K
|
M
|
N
|
O
|
U
|
T
|
F
|
G
|
V
|
LOAD
|
UN-LOAD
|
|
90S
|
0.4 |
Ⅰ
|
235 |
195 |
173 |
140 |
100 |
56 |
19j6 |
40 |
90 |
190 |
10 |
139 |
165 |
102 |
130 |
15.5 |
6 |
6 |
30 |
6204zz |
6204zz |
11
|
|
90L
|
0.75 |
Ⅰ
|
260 |
220 |
173 |
140 |
125 |
56 |
19j6 |
40 |
90 |
190 |
10 |
139 |
165 |
111 |
155 |
15.5 |
6 |
6 |
30 |
6204zz |
6204zz |
16
|
|
|
|
 |
단상 유동 전동기 (방진형)
SINGLE PHASE INDUCTION MOTORS CRADLE BASE TYPE |
| :: 단상 유도전동기(방진형) 4극(POLES) :: |
|
FRAME
NO
|
OUT PUT
|
DIMENSION(mm)
|
KEY SIZE
|
BEARING
|
NET
WEIGHT
(kg)
|
|
KW
|
L
|
S
|
Q
|
A
|
B
|
C
|
D
|
E
|
H
|
I
|
K
|
M
|
N
|
O
|
U
|
T
|
F
|
G
|
V
|
LOAD
|
UN-LOAD
|
|
#48
|
0.2 |
246 |
216 |
144 |
107.7 |
69.85 |
63.5 |
14h6 |
30 |
76 |
150 |
8.6 |
67 |
134 |
85 |
204 |
13 |
- |
- |
- |
6202zz |
6202zz |
7
|
|
#48
|
0.25 |
246 |
216 |
144 |
107.7 |
69.85 |
63.5 |
14h6 |
30 |
76 |
150 |
8.6 |
67 |
134 |
85 |
204 |
13 |
- |
- |
- |
6202zz |
6202zz |
9
|
|
#56
|
0.4 |
301 |
261 |
177 |
124 |
76.2 |
76.2 |
19j6 |
4 |
94 |
165 |
10 |
83 |
165 |
97 |
248 |
15.5 |
6 |
6 |
30 |
6204zz |
6203zz |
12
|
|
#56
|
0.55 |
301 |
261 |
177 |
124 |
76.2 |
76.2 |
19j6 |
40 |
94 |
165 |
10 |
83 |
165 |
97 |
248 |
15.5 |
6 |
6 |
30 |
6204zz |
6203zz |
14
|
|
#56
|
0.75 |
301 |
261 |
177 |
124 |
76.2 |
76.2 |
19j6 |
40 |
94 |
165 |
10 |
83 |
165 |
97 |
248 |
15.5 |
6 |
6 |
30 |
6204zz |
6203zz |
16
|
|
|
|
 |
